AUDIBLE PHYSICS NZ3

Kodas:

540,00 EUR
Su mokesčiais
  • Security policy (edit with Customer reassurance module) Security policy (edit with Customer reassurance module)
  • Delivery policy (edit with Customer reassurance module) Delivery policy (edit with Customer reassurance module)
  • Return policy (edit with Customer reassurance module) Return policy (edit with Customer reassurance module)

Normal Impedance Znom 4 ohm                                             Magnet size 60*5mm
DC resistance Re 3.1 ohm                                                       Voice coil diameter Dc 25.5 mm
Voice coil inductance Le 0.13 mH @1kHz                                   Winding height Hc 3.0 mm
Resonance frequency Fs 101 Hz                                               Linear excusion P-P Xm 8 mm
Mechanical Q factor Qms 0.77                                                  Max excusion P-P 16 mm
Electrical Q factor Qes 0.62                                                      Normal long term Power Pnom 15 W
Total Q factor Qt 0.34 Instant(10ms)                                         Max Power Pmax 30 W
Moving mass(incl.air load) Mms 2.3 g
Suspension compliance Cms 1.0 mm/N                                     Sound Pressure Level/1m/1W SPL 85 dB
Effective dome diameter d 6.1 cm                                             Recommended range 100-20k Hz
Effective piston area Sd 29.2 sq.cm                                           Net. weight 0.5 kg
Equivalent volume Vas 1.3 L                                                     Overall dimension Ф91*42mm
Force factor Bl 2.63Tm
