HELIX C ONE

Kodas:

0,00 €

Su mokesčiais

Output power RMS ≤ 1% THD+N	Normal operation (One amplifier)
- @ 4 Ohms	1 x 525 Watts
- @ 2 Ohms	1 x 830 Watts
- @ 1 Ohm	1 x 1,100 Watts
- bridged @ 4 Ohms	-
- bridged @ 2 Ohms	-
Max. output power per channel*	Up to 1,320 Watts RMS @ 1 Ohm
Amplifier technology	Class AB
Inputs	2 x RCA / Cinch 1 x Remote In 1 x Remote control input 1 x TwinPower Link
Input sensitivity	RCA / Cinch 0.5 - 8 Volts
Input impedance RCA / Cinch	7.5 kOhms
Input impedance highlevel	-
Outputs	1 x Speaker output
Output voltage RCA / Cinch	-
Signal converter for digital input	-
Frequency response	10 Hz - 80,000 Hz
Bass boost	0 - 9 dB / 40 Hz - 120 Hz
Highpass	15 Hz - 4,000 Hz adjustable
Lowpass	15 Hz - 4,000 Hz adjustable
Bandpass	15 Hz - 4,000 Hz adjustable
Subsonic	-
Phase	0 - 180° adjustable
Slope high- / lowpass	12 dB/Oct.
Slope subsonic / lowpass	-
Signal-to-noise ratio digital input	-
Signal-to-noise ratio analog input	120 dB (A-weighted)
Distortion (THD)	< 0.006 %
Damping factor	> 1000
Operating voltage	9 - 16 Volts (max. 5 sec. down to 6 Volts)
Idle current	2400 mA
Operating temperature range	-40° C to +70° C
Fuse	3 x 30 A LP-Mini-fuse (APS)
Additional features	Active, adjustable crossover, bass boost, HDM slot, input mode switch, TwinPower Link, Start-Stop capability
Dimensions (H x W x D)	37.1 x 430 x 240 mm / 1.46 x 16.93 x 9.45"
