HELIX P ONE MK2

Kodas:

0,00 €

Su mokesčiais

Power RMS ≤ 1% THD+N
- @ 4 Ohms	1 x 500 Watts
- @ 2 Ohms	1 x 880 Watts
- @ 1 Ohm	1 x 1,500 Watts
- bridged @ 4 Ohms	-
- bridged @ 2 Ohms	-
Max. output power per channel*	Up to 1.800 Watts RMS @ 1 Ohms
Amplifier technology	Class D
Inputs	2 x RCA / Cinch 1 x Remote In 1 x Optical SPDIF (28 - 96 kHz)
Input sensitivity	RCA / Cinch 0.5 - 8 Volts
Input impedance RCA / Cinch	20 kOhms
Input impedance highlevel	-
Outputs	1 x Speaker output
Output voltage RCA / Cinch	-
Signal converter for digital input	BurrBrown 32 Bit DA converter
Frequency response	21 Hz - 40,000 Hz
Bass boost	-
Highpass	-
Lowpass	-
Bandpass	-
Subsonic	21 Hz
Phase	-
Slope high- / lowpass	-
Slope subsonic / lowpass	Butterworth 48 dB/Oct.
Signal-to-noise ratio digital input	110 dB (A-weighted)
Signal-to-noise ratio analog input	110 dB (A-weighted)
Distortion (THD)	< 0.01 %
Damping factor	> 450
Operating voltage	10.5 - 17 Volts (max. 5 sec. down to 6 Volts)
Idle current	1500 mA
Operating temperature range	-40° C to +70° C
Fuse	4 x 30 A LP-Mini-fuse (APS)
Power rating	DC 12 V ⎓ 160 A max.
Additional features	Input mode switch, SPDIF Direct In switch, Start-Stop capability
Dimensions (H x W x D)	50 x 260 x 190 mm / 1.97 x 10.24 x 7.48”
